Pressol Push type- and suction gun 2014.1-DW

Item No: 12986

For mineral, synthetic and biological oils, diesel, heating oil, antifreeze (window and motor), glycerin, urea up to 10%, water and seawater
The plunger ensures reliable suction of the liquid
All materials that come into contact with the media are of high quality

750 ml-PVC
Technical data
Capacity (ml): 750
Suction volume (%): 100
Diameter tubing outside (mm): 60
Tube thickness (mm): 3
Stroke length (mm): 400
Suction hose diameter (mm): 12
Suction hose length (mm): 600
Discharge hose diameter (mm): 16
Length of discharge hose (mm): 600
Materials of parts in contact with liquid
Head and cover: PAGF 30 (PP glass-fibre reinforced)
Tube: Polycarbonat
Piston: FKM (Viton®)
Piston rod: stainless steel
Valves / connection: aluminium
Valve ball: PTFE
Suction hose: PVC
Discharge hose: PVC
Dimensions LxWxH (mm): 95 x 65 x 450
Weight (kg): 0,6
Specification

Ergonomic T-grip
Suction hose (12 997)
Discharge hose (12 998)
